Shaded Pole Motor (Frame 3.3,4P)
Shaded Pole Motor (Frame 3.3,4P) Shaded Pole Motor (Frame 3.3,4P)
Shaded Pole Motor (Frame 3.3,4P) Shaded Pole Motor (Frame 3.3,4P)
Shaded Pole Motor (Frame 3.3,4P) Shaded Pole Motor (Frame 3.3,4P)
Shaded Pole Motor (Frame 3.3,4P) Shaded Pole Motor (Frame 3.3,4P)
Shaded Pole Motor (Frame 3.3,4P) Shaded Pole Motor (Frame 3.3,4P)

loading

Shaded Pole Motor (Frame 3.3,4P)

Share to:
sharethis sharing button
Availability:
Quantity:
Inquire Add to Basket

Shaded Pole Motor

Description: Compact size, low noise, high efficiency, UL certificated, overload protected, provide various frame size and RPM. Widely used in ventilation, water pump and other industry area. Can develop motor per customer requirements.

TypeSeriesFrameVoltageCurrentPowerRPM
Shaded pole (3.3",4P)HYZ82-6-4 000282.4mm115V 0.51A6W1550RPM
Shaded pole (3.3",4P)HYZ82-30-4 000582.4mm115V 1.26A30W1550RPM
Shaded pole (3.3",4P)HYZ82-19-4 000382.4mm115V 1.1A 19W1550RPM
Shaded pole (3.3",4P)HYZ82-19-4 000582.4mm115V 1.1A 19W1550RPM
Shaded pole (3.3",4P)HYZ82-25-4 000782.4mm115V 1.2A25W 1550RPM
Shaded pole (3.3",4P)HYZ82-30-4 000782.4mm115V 1.26A30W1550RPM
Shaded pole (3.3",4P)HYZ82-38-4 500682.4mm230V 0.72A 38W1550RPM
Shaded pole (3.3",4P)HYZ82-6-4 000582.4mm115V0.51A6W1550RPM
Shaded pole (3.3",4P)HYZ82-38-4 000682.4mm115V 1.65A41W1550RPM
Shaded pole (3.3",4P)HYZ82-19-4 500182.4mm240V0.55A28W1550RPM
Shaded pole (3.3",4P)HYZ82-6-4 0001 82.4mm115V 0.51A6W1550RPM
Shaded pole (3.3",4P)HYZ82-30-4 000682.4mm115V 1.39A 30W1550RPM
Shaded pole (3.3",4P)HYZ82-30-4 000882.4mm115V 1.26A30W1550RPM
